In our store, you will find over 2500 thousand, Workshop, Service, Installation, Parts, Owners, Information manuals and Schematics, in a DIGITAL FORMAT ready to DOWNLOAD.
We can supply EPC software for Windows XP and Windows 7 packages to cover all models, for workshop and part manuals. These software packages are most suited for the professional or for a workshop.
Our collection of manuals are mainly for marine and some heavy equipment engines, current and old models. Our manuals and software have been carefully selected.and they are in a DIGITAL FORMAT ready to be dowloaded
Please select from the menu on the left your engine manufacturer, or use the search box on the top right hand of the menu bar to find your manuals. To search, you must use your engine model in different variations for better results, e.g., M17 or Sole M17, 4.108M or Perkins 4.108. Or, just use the engine manufacturer, e.g., Perkins, Bukh, Sole, etc.
We handpick and thoroughly check our electronic manuals before we put them up for sale. We also supply these manuals on soft copy DVDs at an extra cost. We ship worldwide.
Special arrangements can be made for "express courier" at a reasonable price, through your courier or ours. Do not hesitate to contact us for a price or to place an order.
WE ADVICE THAT YOUR DOWNLOAD LINK WOULD BE ACTIVE FOR 24Hrs. FROM THE TIME OF THE PURCHASE
ATTENTION: Due to the nature of our product we can not accept product returns or offer refunds. Please choose carefully and if you are in doubt contact us before you make a purchase. We strongly advise you to read our Terms and Conditions before you place an order. For more information, please contact Sales
Stray Current: (an explanation)
. Stray current is electricity that is flowing where it's not supposed to, mainly through: water, metal fittings on your boat, wet wood, damp surfaces, propeller shaft(s) etc. and can cause corrosion (technically known as electrolytic corrosion). Stray current corrosion is caused by a power source, such as your batteries or the shore power connection. The stray current can cause serious electrolityc corrosion damage, because of the relatively high driving voltages (shore power) stray current corrosion, can act far more quickly than the corrosion caused by dissimilar metals in contact (galvanic corrosion).
Common Ground Point: (ship's ground)
. Grounds from batteries, engine, switch-panel, negative bus bar, bonding system, auxiliary power generator, underwater ground plate, ship's 120-240AC Volt safety-ground, and LORAN/RADAR signal(s)-ground, must all be connected at one grounding point, this must be a heavy bus bar or bracket with bolted connections, thismust be easy to access and must be located above bilge levels as practicable and be labeled as Common Ground Point(s)
Batteries: (know how)
WARNING! The hydrogen gas inside lead-acid batteries is explosive and can burn your skin and eyes. Avoid sparks or open flames and wash well after handling your battery.
The acid level inside the battery must cover the top of the plates. Letting the acid level below the top of the plates will cause serial battery damage. Use distilled water to top up the batteries. If distilled water isn't available, rain water can be used instead if it's clean from foreign particles. If rain water is going to be used then it must be filtered beforhand. . The battery is fully charged when the specific gravity of the electrolyte is between 1.245 to 1.300 in each cell. In a partially discharged battery, the specific gravity variation between cells must not vary by more than 0.050. The battery cells (plates) sometimes after been charged can have uneven (specific gravities) values, but after been discharged, for about 25% (from a full charge) they even out, if not then this battery need to be replaced
NOTE: If the battery has been left for along time without been charged , it is possible for the acid to separate from the water and settled to the bottom, leaving a lower specific gravity electrolyte on the surface, or if you overfilled the battery then the electrolyte may be over diluted. Either of these situations can result in abnormally low readings and they don't necessarily indicate a weak or damaged battery cell. . The battery voltage 'at rest' must be between 12.1 to 12.9 Volts A battery is 'at rest' when it isn't being used and hasn't received a charging or been discharged for at least 12 hours. A voltage above 12.9 Volts indicates that the battery is still settling after a charge. A voltage below 12.1 Volts indicates either a weak cell or a battery charge below 50% of capacity.
. Standard batteries have their life span shortened drastically by deep discharges, even to the 50% level. True deep cycle batteries (see below) function well with 50% discharges. . To test the bateries, crank the engine for 3-5 seconds with each battery, the battery voltage must be above 9.5 Volts and steady whilst cranking. This test must be done after the engine has been run so that the engine oil has been circulated, you must disconnect the coil's '+' wire (Pertol engine) or turn the diesel fuel shut-off (Diesel engine) to prevent the engine from starting. Some times it's possible for a battery to fail this high current test while still being able to provide good storage capacity at lower currents. This can happen if the starter to the battery cable/connection, condition and size, are outside the factorys specifications .
. If an engine doesn't crank properly and or the battery voltage remains high, then there is a problem with the starting circuit or the starter motor.
Note: Starter and electric winch motors will normally 'pull' a battery's voltage down to 9 or 10 Volts while they're operating. The battery should recover most of its voltage 'at rest' within seconds.
